MÔ TẢ

1. 5.1 decoder, double channels microphone setting, music DEQ.

2. Whith speaker management functions, main channel subwoofer, center and surond can set independently.

3 PEQ

4. New software, support data save ane send , easy to operate.

5. Echo/Reverb with 7 bands PEQ

6. Music and microphone data can be set at Surround(and subwoofer) channel.

7 Every channels has delay function, suitable for any size roooms and speaker placement.

8. The fifth generation feedback project.

9. New circuit design, wide frequency response, high speed CPU, processing more clearly.

10. With record output, output date can be set independently.

11. Admin/user mode switchchover to insure safety.



CHI TIẾT SẢN PHẨM

Technical Specification

– Music

SNR >90db
THD ≤0.6% output XLR 1Vrms 1KHz
Frequency response 10Hz – 20KHz ≤±3db
Input 350±10%mv/20kohm
Output ≥2.5Vrms XLR out/≥6.0 Vpp XLR out
Gan 10db±1.0db

– Microphone

SNR ≥80db
THD ≤0.8% output XLR 1Vrms 1KHz
Frequency response 100Hz – 20KHz ≤±3db
Input 50mv±10%mv/2kohm
Output ≥2.5Vrms XLR out/≥6.0 Vpp XLR out
Gan 26db±1.5db

– Other functions

Mic input socket 6.35 MIC socket 5piece
Computer connecting port USB connecting port
Power supply AC 220V/50HZ
Fuse F2A/250VAC
Power AC 220/50HZ±10
Weight 4.2kg±10%
Size 483(L|mm*205|W)mm*44(H)mm
